Belt CVT cut-away model
   |
■ The order number and the product name:
C460e-CVT Belt CVT cut-away model
■ The product description:
Using the belt type continuously variable transmission mission which is used for the actual passenger car, the watching of a belt brake shield, front part and so on applies a possible cut process and it is operating Pooley and a planetary gear by the air operation and turning a handle and the status which is near the actual continuously variable transmission operation can be simulated.
Only the air which is necessary to operate connects with the compressor of the durability!
It is the operation type cut total vehicle to have made a cut total vehicle have a feature as the simulator.
The sound package: CD-ROM soft " the operation of the continuously variable transmission "
One sheet
The size and the weight: 1150 × 660×800㎜ 60 kg
